Maximum Capacity

24000 pcs/hour

machine weight

600kg _

Machine volume

980×710×1880mm (height with powder feeding machine: 2290mm)

power supply

380/220V 50Hz

total power

3kw _

Number of holes

3 holes

Vacuum

20m 3 /h -0.04～-0.08MPa

vacuuming

17.6Kpa 180m³/h

compressed air

Air consumption 4m³/h Pressure 0.3～0.4MPa

working noise

≤75dBA

Working temperature

21°C±3°C

working relative humidity

40-55%

Chance

Empty capsule ≥ 99.9%. Full capsule ≥ 99.8%

Adapt Capsules

00#-5# capsule

Loading accuracy

Western medicine ± 3%. Traditional Chinese medicine ± 4%

Adapt to the filling range

Powder, Granule, Pellet, Tablet

special function

Powder collector function

Material

316L stainless steel is used for parts in direct contact with medicines

specification

Fully sign cGMP requirements
