Maximum Capacity

48000 pcs/hour

machine weight

900 kg

Machine volume

1060×860× 1990 mm ( height with powder feeder: 2400mm )

power supply

 380/220V 50Hz

total power

5kw _

Number of holes

6 holes

Vacuum _

40m 3 /h  -0.04 ～ -0.08M P a

vacuuming

24.5Kpa 210m 3 /h

compressed air

Air consumption 5 m 3 /h Pressure 0.3～0.4MPa

source of water

Water flow 500L/h 0.1～0.2Mpa

water requirements

The water ring vacuum pump and the water tank are recycled, and the water source can be connected externally

working noise

≤ 75dBA _

Working temperature

21°C±3°C

working relative humidity

40-55%

Chance

Empty capsule ≥ 99.9%. Full capsule ≥ 99.8%

Adapt Capsules

00#-5# capsule

Loading accuracy

Western medicine ± 3%. Traditional Chinese medicine ± 4%

Adapt to the filling range

Powder, Granule, Pellet, Tablet

special function

Powder collector function

Material

316L stainless steel is used for parts in direct contact with medicines

specification

Fully sign cGMP requirements
